XTT ICR18650 2200mAh Li-ion Battery

Product Details

• Product type: Lion-ion rechargeable battery
• Model: 18650
• Dimension: 18m x 65mm (diameter x length)
• Shape: cylindrical
• Weight: 41g
• Package contains: 1 x XTT ICR18650 2200mAh Li-ion Battery

18650 Li-ion battery is a lithium-ion rechargeable battery and used in high drain application due to its superior capacity and discharge rate. The first 4 digits of 18650 indicate its dimension i.e. 18mmx65mm and the last 5th digit indicates its shape i.e. cylindrical. Li-ion batteries can usually boast a 300-500 charge cycle.

Features

Small size and easy to use

Great capacity and discharge rate Long life

Specification

Minimum capacity: 2200mah

 Typical capacity: 2260mah

Internal impedance: 1 ohm

Standard voltage: 3.7V

Overcharge voltage: 4.78V to 4.92v

Maximum safe discharge current: 4400mA(C)

Maximum charging current: 4200mA

Over discharge voltage (under a constant load of 11.4Ohm/500mA)

0.01V voltage drop/5-min

0.12V voltage drop/60-min

Final discharge voltage: 3.86V dropped to 2.46 in 7 hours mav
