MIC29302 LDO Voltage Regulator IC - TO-263 SMD Package Q1 C13

MIC29302 LDO Voltage Regulator Key Features:

Type: Low Dropout (LDO) Voltage Regulator

Package: TO-263 (Surface Mount Device)

Output Voltage: Adjustable from 1.24V to 26V

Maximum Output Current: 3A

Dropout Voltage: Typically 350mV at 3A

High Accuracy: ±2% output voltage tolerance

Low Quiescent Current: Typically 4mA

Thermal Overload Protection: Protects the IC from overheating

Short-Circuit Protection: Protects against excessive current draw

Applications:

Power Supplies: Suitable for use in regulated power supply circuits.

Industrial Equipment: Used in various industrial applications requiring stable voltage.

Consumer Electronics: Ideal for providing stable voltage in consumer electronic devices.

Telecommunication: Useful in telecommunication equipment requiring regulated voltage.

Battery-Powered Devices: Suitable for battery-powered applications due to low dropout voltage.

MIC29302 SMD IC Pin Configuration:

Pin 1 (Adj/GND): Adjust pin for setting the output voltage (ground for fixed output versions)

Pin 2 (Vout): Regulated output voltage

Pin 3 (Vin): Input voltage

Tab: Internally connected to Pin 2 (Vout) for heat dissipation

Electrical Characteristics:

Input Voltage (Vin): Up to 26V

Output Voltage (Vout): 1.24V to 26V (adjustable)

Output Current (Iout): 3A max

Dropout Voltage: 350mV typical at 3A

Quiescent Current: 4mA typical

Output Voltage Tolerance: ±2%

Line Regulation: 0.015%/V typical

Load Regulation: 0.1% typical

Package Includes:

1 x MIC29302 LDO Voltage Regulator IC - TO-263 SMD Package
