Metal Detector Kit

Product Specifications

• Product Type: Metal Detector Kit
• Brand: Vegakit
• Package contains: All the components as described with complete manual

The metal detector is useful to detect Metallic objects. it can also detect a slightly big size metallic object. it has a sensing coil which is kept near a metallic object for detection.

when a coil is brought near a metallic object magnetic energy is absorbed and oscillator fails to work.  Then final transistor conducts and buzzer is activated.

Components list in the Kit

Resistors

R1 R4: 56k

R2: 3k3

R3: 22k

R5: 2k7

R6: 2k2

R7 R9: 680 E

R8: 15

P1: 5k 3386 Trim pot

Capacitors

C1 C6: 0.1 PF

C2: 1KPF

C3: 220 PF

C4: 270 PF

c5: 12KPF 100V

C7: 100 uF 25V

BC547

1N4148

5mm Red Led

metal Detector Coil

Buzzer

9 v Battery Snap

PCB
