FlySky FS-IA6B RF 2.4GHz 6CH PPM Output with iBus Port Receiver C7 B3

The FlySky FS-IA6B RF 2.4GHz 6CH PPM output with iBus port receiver works great with the FlySky FS-i6 Controller.

This compact 6-channel receiver is great for any model using up to 6 channels and, with a range exceeding 500 meters, it can be considered to be the full range for all but the most demanding of applications. The receiver has end-on connectors to enable a neat installation in tight spaces.

This has Fly Sky FS IA6B RF 2.4GHz 6ch PPM output with iBus port receiver built-in connectors which allows you to use any of the optional FlySky telemetry sensors. Dual antennas give the FS-iA6B excellent reception and interference rejection capability. With easy binding, compact dimensions, optional telemetry, and dual antennas.

We have a range of such transmitters and receivers which are can be used to fulfill your unmanned vehicle requirements.

Package Includes:

1 x Fly SkyFS IA6B RF 2.4GHz 6CH receiver.

1 x Bind Plug.

Specifications:

Model

FS-iA6B

Operating Voltage (VDC)

4.0 ~ 8.4V

No. of Channels

6

No. of Band

140

Encoding

GFSK.

RF Range

2.4055–2.475 GHz.

Rx Sensitivity (dBm)

-105

Antenna Length (mm)

26

Video Format Supported

NTSC/PAL

Color

Black

Dimensions (mm) LxWxH

47 x 26.2 x 15

Net weight (gm)

14.9
