1N5822 Schottky Rectifier Diode Q1 C6

Name: 1N5822 Schottky Rectifier Diode Q1 C6
SKU: SKU-6550
Price: 9 INR
Availability: InStock

₹ 9

₹ 10

10%

Delivery Options

Get delivery at your doorstep

Schottky diodes have low forward voltage drop and fast switching speeds compared with a rectifier diode. This makes the diode to be popularly used in reverse polarity protection circuit and other time constraint switching circuits. The downside of the diode is that it has low reverse breakdown voltage. The features of the 1N5822 diode are

Forward Voltage drop: 0.39 @ 1A

Reverse Voltage: 28V (RMS)

Forward Current: 3A

Forward surge current: 80A

Guardring for overvoltage protection

Very small conduction losses

Extremely fast switching

Low forward voltage drop

High forward surge capability

High frequency operation

Solder dip 275 °C max. 10 s, per JESD 22-B106

Typical 1N5822 Diode Applications:

Used in low voltage high frequency inverters

DC-DC converters

Polarity protection applications

Package Includes:

1 x 1N5822 Schottky Rectifier Diode
