IRFP064N 55V 110A N-Channel Power MOSFET TO-247 Package

Product Details

• Product: IRFP064N
• Transistor type: MOSFET
• Control channel: N-channel
• No of pins: 3
• Package: TO-247
• Mounting type: through hole
• Package contains: 1 x IRFP064N 110V 81A N-Channel Power MOSFET

Features

Dynamic dv/dt capability

Advanced process technology

Ultra low on resistance

Fully avalanche rated

Fast switching

L175? operating temperature

Specification

Drain-source voltage: 55V

Drain-gate voltage: 55V

Gate-source voltage: �20V

Continuous drain current:

At 25?: 110A

At 100?: 80A

Pulsed drain current: 390A

Avalanche current: 59A

Maximum power dissipation: 200W

Operating temperature: -55? to 175?
